Specifications
System Overview
System memory 558/458: 4,096 MB (standard)
System hard disk 250 GB (standard)
Interface 10-BASE-T/100-BASE-TX/1,000-BASE-T Ethernet, USB 2.0 Wi-Fi 802.11a/b/g/n/ac (optional)
Network protocols TCP/IP (IPv4/IPv6), NetBEUI, SMB, LPD, IPP, SNMP, HTTP
Frame types Ethernet 802.2, Ethernet 802.3, Ethernet II, Ethernet SNAP
Automatic document feeder Up to 100 originals, A6-A3, 35-163 gsm
Printable paper size A6-SRA3, customised paper sizes, banner paper max. 1,200 × 297 mm
Printable paper weight 52-300 gsm
Paper input capacity Standard: 1,150 sheets, Max.: 6,650 sheets
Tray 1 500 sheets, A5-A3, 52-256 gsm
Tray 2 500 sheets, A5-SRA3, 52-256 gsm
Tray 3 PC-110 (optional) 500 sheets, A5-A3, 52-256 gsm
Tray 4 PC-210 (optional) 2 × 500 sheets, A5-A3, 52-256 gsm
Paper feed cabinet
PC-410 (optional)
2,500 sheets, A4, 52-256 gsm
Large capacity unit
LU-302 (optional)
3,000 sheets, A4/Letter, 52-256 gsm
Large capacity unit
LU-207 (optional)
2,500 sheets, A4/Letter – SRA3/Ledger, 52-256 gsm
Bypass tray 150 sheets, A5-SRA3, custom sizes, banner, 60-300 gsm
Automatic duplexing A5-SRA3, 52-256 gsm
Finishing modes (optional) Group, sort, staple, punch, output tray, booklet, centre fold , letter fold, Z-fold
Power consumption [220-240 V, 50/60 Hz] less than 558: 2.00 kW, 458: 1.95 kW (system)
[120 V, 60 Hz] less than 558: 1.65 kW, 458: 1.5 kW (system)
[110 V, 50/60 Hz] less than 558: 1.65 kW, 458: 1.5 kW (system)
System dimensions [W × D × H] 615 x 685 x 921 mm (24.2 x 27.0 x 36.3 inch) *1
System weight Approx. 93 kg (205.0 lb) *2

*1 Excluding ADF and lower paper tray unit.

*2 Main Body: 81 kg (178.8 lb) + DF-704 (standard): 12 kg (26.5 lb)

Back to Top

Copier Specifications
Copying process Electrostatic laser copy, intermediate
Toner system Simitri® HD Polymerized Toner
Copy/print speed A4 558: Up to 55 ppm, 458: Up to 45 ppm
1st copy out time 558: 3.5sec., 458: 4.0 sec.
Warm-up time *3 558:22 sec. or less 458: 25 sec
Copy resolution 600 × 600 dpi
Gradation 256 gradations
Multicopy 1-9,999
Original format A5-A3
Magnification 25-400% in 0.1% steps, auto-zooming

*3 Warm-up time may vary depending on the operating environment and usage.

Back to Top

Printer Specifications
Print resolution 1,800 (equivalent) × 600 dpi, 1,200 × 1,200 dpi
Page Description Language PostScript 3 (3016) Emulation,
PCL 6 (XL Version 3.0) Emulation, PCL 5e/c Emulation, XPS
Operating systems Windows Vista (32/64), Windows 7 (32/64),
Windows 8.1 (32/64), Windows 10 (32/64),
Windows Server 2008 (32/64), Windows Server 2008 R2,
Windows Server 2012, Windows Server 2012 R2,
Macintosh OS X 10.7 or later, Linux, Unix, Citrix
Printer fonts 80 PCL, 137 PostScript 3 Emulation
Mobile printing AirPrint (iOS), Mopria (Android), Google Cloud Print (optional),
Wi-Fi Direct (optional), Konica Minolta Print Service (Android),
PageScope Mobile (iOS, Android, Windows 10 Mobile)

Back to Top

Scanner Specifications
Scan speed*8 with DF-704 1-sided original: 80 opm
2-sided original: 160 OPM
Resolution Max.: 600 × 600 dpi
Scan modes Scan to Email, Scan to PC (SMB), Scan to FTP, Scan to WebDAV, Scan to BOX (HDD), Scan to WSD (Web Service), Scan to DPWS (Device Profile for Web Service), Scan to USB memory, Network TWAIN scan
File formats JPEG, TIFF, PDF, PDF/A-1a (optional), PDF/A 1-b (optional),
XPS, compact XPS, PPTX, searchable PPTX (optional),
compact PDF, encrypted PDF and searchable PDF (optional),
searchable DOCX/XLSX (optional)
Destinations 2,100 (single + group), LDAP, PSDA support

*8 When copying A4 or Letter (8-1/2 × 11), resolution 600 dpi

Back to Top

Fax Specifications (optional)
Fax Super G3
Transmission Analog fax, Internet fax, Colour Internet fax, IP address fax
Resolution Max.: 600 × 600 dpi (ultra-fine)
Compression method MH, MR, MMR, JBIG
Modem speed Up to 33.6 Kbps
Destinations 2,100 (single + group)

Back to Top

— All specifications refer to A4-size paper of 80 gsm quality.
— The support and availability of the listed specifications and functionalities vary depending on operating systems, applications and network protocols as well as network and system configurations.
— Some of the product illustrations contain optional accessories.
— Specifications and accessories are based on the information available at the time of printing and are subject to change without notice.
— Konica Minolta does not warrant that any specifications mentioned will be error-free.
— All brand and product names may be registered trademarks or trademarks of their respective holders and are hereby acknowledged.

Where to Buy

Please select your product type / state / city from below for contact information.

Where to Buy

Please select your product type / country / city from below for contact information.

Contact Us
Name *

Email *

Phone No.

Message *

Enter Security Code captcha

Customer Care (Toll Free)
1-800-266-2525

Back to Top

Fast startup and output.



*1 WUT(Warm-up Time) :
The time between when the power switch is turned on and when copy operation can start.

*2 FCOT(First Copy Out Time) :
The time between when the Start button is pressed and the end of output of the first copy page.

A five-line graphical display for more clearer indications and simple guidance is available on the LCD screen.
This result in less time spent on searching information in the product manual.


CLOSE

Variety of duplex copy methods to fulfill different purposes.

- 1-sided ➞ 2-sided*1 :
Automatic double-sided copying.
- 2-sided ➞ 1-sided*2 :
A double-sided document can be copied into 2 pages with 1-sided each.
- 2-sided ➞ 2-sided*3 :
Automatically copy double-sided document to one sheet of paper.
*1 Optional Auto Duplex Unit AD-509 is required.
*2 Optional Reverse Automatic Document Feeder DF-625 is required.
*3 Optional Auto Duplex Unit AD-509 and Reverse Automatic Document Feeder DF-625 are required.


Output from a Linux environment is also available.

Red Hat Enterprise Linux 5 (CUPS Ver1.2.4) ×86
Red Hat Enterprise Linux 5 (CUPS Ver1.2.4) AMD64/Intel64
SUSE Linux Enterprise Desktop 11(CUPS Ver1.1.23) ×86
SUSE Linux Enterprise Desktop 11(CUPS Ver1.1.23) AMD64/ Intel64

Multi-page documents can be printed on one sheet. 2-in-1 prints 2 pages on 1 sheet, and 4-in-1 prints 4 pages on 1 sheet.


One touch ID Copy button allows you to copy the front and back side of any small documents such as Passport, Employee-id, Driving licence into one sheet of paper.
The readable range is up to A5 size.

CLOSE

The scanned files can be saved directly to USB memory, or sent to different destination such as E-mail*1, SMB*1 or FTP*1. The supported scan formats are TIFF, PDF and JPEG.
*1 Optional Network Interface Card NC-504 or PCL controller with NIC IC-209 and Option Panel MK-749 are required.

CLOSE

Both sided documents can be scanned automatically at once with optional RADF(Reverse Automatic Document Feeder DF-625).

Scan performance (1-sided per minute)

* When equipped with the Reverse Automatic Document feeder DF-625.
CLOSE
With the Konica Minolta's own Toner Loop Mechanism technology, there will be no more waste toner.
CLOSE

Different types of Watermarks can be added on the documents based on the purpose or importance level of documents.

The MFP can be set to request a 3-digit account number to use the Copy feature. To restrict users who are not authorized to use the MFP. Also, numbers of copies made under each account can be tracked.

The MFP will not perform any outputs until user enters the same password as it has been set in the printer driver. To prevent highly confidentiality documents being left on the MFP or taken by unauthorized user.
