The Innex CM55 is a next-generation mobile all-in-one meeting hub designed to bring effortless collaboration, video conferencing, and creativity to business and education environments. It combines a 55-inch 4K UHD interactive display, an AI-powered 8MP wide-angle camera, and 8-microphone array, all packed into a slim, portable design ideal for dynamic teamwork and hybrid setups.
Download Flyer
Gallery mode detects up to 5 people and creates an individual close-up shot for each person, providing an immersive meeting experience.
Auto-Framing automatically detects where people are seated within its wide-angle view, centers them in the frame, and trims excess space on both sides.
Speaker Tracking mode detects and tracks the active speaker with advanced audio recognition, making it perfect for presentations.
Experience seamless wireless connectivity with the all-in-one Innex CM55. With full BYOM support, use your own laptop and access everything you need in video conferencing, including the built-in camera, mic-array, speakers, screen casting and touch back.
The integrated wide-angle camera features AI-powered display modes, including auto-framing, gallery, and speaker tracking.When screen casting via Connect Pro Button, you can wirelessly access the Innex CM55 camera and 8-microphone array from the laptop, without requiring an extra cable connecting between your laptop and conference camera.
The Innex CM55 whiteboard software enhances collaboration through an intuitive, interactive workspace. Users can annotate and capture screenshots directly from their laptops during screen sharing, integrating them seamlessly into the whiteboard for a more dynamic idea-sharing experience.
Designed with your utmost convenience in mind, the remote control uniquely combines command over the built-in camera and the display. No need to download additional software or apps - you can easily manage everything with just one remote. Adjust camera modes, change viewing angles, and tailor other settings to your preferences effortlessly.
Effortlessly move the display around rooms, transforming any corner into a creative and collaborative meeting space. Enhance productivity, foster innovation, and unlock the full potential of your meetings with unmatched flexibility and convenience.
| Display Dimension | 55" |
|---|---|
| Dynamic Contrast | 5000:1 |
| Response Time | 8 ms Typ |
| Low Blue Light | Yes |
| Panel Type | IPS |
| Back-Light | E-lit LED |
| Viewing Angle | 178° |
| Brightness | 350 Typical |
| Resolution | Ultra HD 3840 x 2160 |
| Color Depth | 1.07B Colors |
| Color | 72% NTSC |
| Aspect Ratio | 16:9% |
| Panel Frequency | 60Hz |
| Touch Technology | P-CAP Touch | |
|---|---|---|
| Touch Surface | 2H Film | |
| Bonding Type | Optical Bonding | |
| Pen | Support MPP Pen(1.5/2.0) | |
| Accuracy | Pen ±1 mm (0.04 in); Finger ±1.5 mm (0.06 in) | |
| Touch Points | 10 Points |
| Speaker Output | 10W x 2 | |
|---|---|---|
| Built-in Camera | 8MP Sony IMX-415 sensor with FOV 120° | |
| Camera Function | Support Remote Control; Support Auto-Framing, Gallery, Speaker Tracking, Manual Mode | |
| Microphone | 8 Mic Array with AGC / ANR / AEC |
| CPU | Quad Core, A55*4, 1.9Ghz | |
|---|---|---|
| GPU | Mali G52MP2 | |
| NPU | 2.6 TOPS |
|
| RAM | 8GB | |
| ROM | 64GB |
| Model name | SI07B | |
|---|---|---|
| Wi-Fi technology | WLAN b/g/n/ax, 5G WLAN a/n/ac/ax | |
| Antenna | Build-in Antenna board | |
| Power | 5V-1A |
| Front | IR Receiver x2 | |
|---|---|---|
| Rear | Power Button x1 Reset Button x1 HDMI In x2 USB-A 3.0 x1 (Embedded system) USB-A 2.0 x2 (Embedded system) USB-C x1 (OTG / Connect Pro pairing) USB B for Touch x1 Line Out x1 RJ 45 In x1 OPS Slot x1 AC In x1 |
| Receiver | Embedded Screen share SW | |
|---|---|---|
| Protocol | Connect Pro Button(BYOM), Airplay, Miracast, Chromecast |
| Accessory | Connect Pro Button x2, MPP Pen x1 (Charged by USB-C), Remote Control x1, AAA Battery x2, Wi-Fi module, Mobile Stand, 1.5M (4.92ft) HDMI Cable x1, 1.5M (4.92ft)USB B-A Cable x1, 3M (9.84ft), USA Power Cable x1, 3M (9.84ft) EU Power Cable x1, 3M (9.84ft), UK Power Cable x1, 3M (9.84ft) India Power Cable x | |
|---|---|---|
| Certification | CE, FCC, BSMI, BIS |
